10nm DC12-48V Channel Aids Navigation Lantern Light PC Lampshade

Place of Origin Guangdong,China
Brand Name Green Source
Certification ISO/SGS/CE/RoHS/CB/IEC
Model Number GS-HD-155
Minimum Order Quantity 1pc
Price Negotiable
Packaging Details Carton package
Delivery Time 3-10 days
Payment Terms TT, Paypal, Visa
Supply Ability 1000pcs/week
Product Details
Product Name DC12v Lighthouse Beacon Lights Light Source Service Life >100000 Hours
Emitting Color Red,Blue,White,Green,Yellow Power Supply AC220V /DC12V
Battery Life >5years Solar Panel Life >20years
Vertical Divergence >10° Horizontal Out-put 360°
Light Solution Service Lighthous Beacon Lights
High Light

10nm Navigation Lantern Light


Channel Aids Navigation Lantern Light


PC Lampshade Lighthouse Beacon Lights

Leave a Message
Product Description

Charging Type 10nm DC12-48V Channel Aids To Navigation Lantern Light



GS-HD-155 Marine lantern adopts advanced structural design.

The control circuit adopts micro-power control chip, which can reduce controlling circuit ’s power consumption.

Light source adopts imported LED chip, which has specific of high light intensity, low power consumption, long service life and so on.

The product shell is made of marine-grade special material, with light weight and corrosion resistance, which is very convenient for installation and transportation.

The lampshade is made of PC material, which is corrosion resistance, anti-UV and anti-shock.




Model GS-HD-155
Power Supply DC12-48V, DC2.5-15V
Optional Emitting Light Colors Red, Amber Yellow, Green, Blue, White
Visual Range 1~12NM
Light Source Life >100000 hours
Light Source LED
Vertical Divergence >8°
Horizontal Out-put 360°
Overall Size(mm) D240mm×310mm
Installation Size(mm) 175~205mm×M16×4/3pcs
Working temperature -40℃~70℃
Storage temperature -40℃~70℃
Weight 2.1KG
Wind-speed Ability 80m/s
Sun Switch Illumination Threshold 300LUX±100LUX



Function & Features

  1. Photocell can switch ON/OFF the light in rainy days or at night automatically.
  2. Standardization of optical design, high photoelectric conversion efficiency.
  3. Adopts special customized LED chip,transfer efficiency and service life is higher than normal LED.
  4. Provide ability of lightning protection, light fastness, resist snow and rain.
  5. Wide voltage input range, can automatically adapt to various power supply occasions.
  6. No radio frequency, no electromagnetic interference.
  7. Steady working, low cost.

Usage notice
1. Please read the instruction carefully and then use the device correctly.
2. Solar powered marine lantern must be installed in a sunny place to keep it working continuously.
3. Please install this light on the Installation plane that perpendicular to light axis, installation plane should has mechanical strength.
4. If the device fails to work at the first using time, please place the device under sunlight to recharge power 12hours, it will work.
5. Please turn off the device and put it in a dry place, to ensure the life of the battery.please put it in a sunlight for 5day(s) to recharge power each 3 months if it needs to be stored for a long time.
6. If there any other problem please contact us.

Sea buoy
River way
Shore beacon
Fixed light pile
Oil field

Dimension drawing
